9-13
Business days: 5 standard PCBA samples
AOI · ICT
+ flying probe test
IPC-A-610
Electronics assembly quality standard
0.35 mm
Minimum BGA pitch
What is PCB Assembly (PCBA)?
PCB assembly (PCBA) is the process of soldering components onto a printed circuit board with SMT and THT methods to turn it into a working electronic board. Utronix performs single- and double-sided assembly to the IPC-A-610 standard, with AOI, flying probe and ICT testing. A standard PCBA sample order of 5 pieces ships from our Istanbul warehouse to your address within 9-13 business days, at affordable prices. PCB and PCBA production is carried out in collaboration with JLCPCB.
What are SMT and THT assembly and how do they differ?
SMT (surface-mount technology) solders components directly onto the board surface, while THT (through-hole technology) passes component leads through holes and solders them. SMT is fast for small, dense boards; THT is used for parts needing mechanical strength, such as connectors. Many boards use both.
Can you assemble BGA, QFN and very small components (0201, 01005)?
Yes, BGA, QFN and components as small as 01005 / 0201 can be assembled; the minimum pitch for standard BGAs is 0.35 mm. For these assemblies we check the manufacturability of the board and parts. Upload your files or contact us for details.
What is a BOM and why must it be LCSC-compatible?
A BOM (bill of materials) lists every component on the board: reference, value, footprint and part number. Because we work with JLCPCB, parts are matched to LCSC part numbers; an LCSC-compatible BOM speeds up sourcing and lowers the risk of errors. You can download a sample BOM from the order process.
Why Utronix?
Our Capabilities
PCB and PCBA Manufacturing Capabilities
Technical capabilities from multilayer PCB manufacturing to fine-pitch BGA assembly, backed by the infrastructure of our manufacturing partner JLCPCB.
PCB Assembly (PCBA)
- Minimum component size
- 01005 / 0201
- Minimum BGA pitch
- 0.35 mm (standard) / 0.5 mm (economic)
- Assembly type
- SMT and THT, single / double sided
- Board size range
- 10 × 10 – 470 × 500 mm
- Soldering
- Nitrogen reflow, wave, selective soldering
- SMT
- THT
- BGA
- QFN
- Flex PCB assembly
- Prototype and series production
Sectors We Serve
- Autonomous Technologies
- Defense Industry
- Automotive & Transportation
- Communication Technologies
- Robotics & Automation
- Energy Sector
- Health & Medical
- Aviation
- Consumer Electronics
How It Works
A Practical PCB Manufacturing & Assembly Pricing and Order Process
Upload your Gerber, BOM and Pick & Place files; price, quote, payment, sourcing, production, testing and shipping in one flow. Delivery from our Istanbul warehouse to every province in Türkiye.
01
Upload Your Production Files
Upload your PCB Gerber files, your LCSC-compatible BOM list and your Pick & Place (coordinate) file to our online order system. Because we work with JLCPCB, it is enough for your BOM to match LCSC part numbers.
02
Price, Quote and Payment
Your files are reviewed, the price is calculated and your quote is sent to you. Once you approve the quote and pay, component sourcing and PCB production begin.
03
Testing and Analysis
Your manufactured and assembled boards go through testing and analysis before delivery.
04
Delivery of Your Boards
Your order is shipped from our Istanbul warehouse to every province in Türkiye and delivered to your address.
Certificates and Standards
ISO 9001
Quality Management System
IPC-A-610
Electronic Assembly Quality Standard
PCB Assembly (PCBA): Frequently Asked Questions
Do you offer PCB assembly (PCBA)?
+
Yes, besides bare PCB manufacturing, Utronix offers SMT and THT assembly (PCBA). Send your Gerber, LCSC-compatible BOM and Pick & Place files and we manage component sourcing, assembly and mounting in one place. Assembly quality follows the IPC-A-610 standard. A standard PCBA sample order of 5 pieces ships from our Istanbul warehouse to your address within 9-13 business days, at affordable prices.
What is a Pick & Place (CPL) file and how is it created?
+
A Pick & Place (CPL) file gives each component's X-Y position, rotation and board side; the assembly machine places parts accordingly. Most PCB design tools generate it automatically. Columns: Designator, MidX, MidY, Layer, Rotation.
How is PCB assembly (PCBA) priced?
+
Assembly price is made up of the PCB fabrication cost, component cost, assembly labour and set-up items (stencil, machine preparation). The number of components, the number of unique parts and single- or double-sided assembly all affect cost. When you upload BOM and Pick & Place files, the items are combined into one quote. Utronix offers assembly at affordable prices.
Do you offer urgent PCB assembly (fast PCBA), and how can I shorten the lead time?
+
Yes, Utronix offers fast PCB assembly (PCBA); for urgent projects just state the urgency at the quote stage, and the time, based on board complexity, quantity and component stock, is stated in the quote. To shorten lead time, prepare an LCSC-compatible BOM and a correct Pick & Place file, prefer in-stock components and upload all files completely in one go. A standard PCBA sample order (5 pieces) ships within 9-13 business days.
Our Other Services
- PCB ManufacturingFast and reliable supply for multilayer PCB manufacturing, from prototype to series production.
- Turnkey ProductionFrom design to delivery under one roof: PCB manufacturing, assembly and component sourcing together.
- PCB Design & Project SupportFrom design review to manufacturability analysis, technical support at every step of your project.
- Component SourcingUninterrupted supply of genuinely sourced components with flexible MOQs and a multi-supplier network.
- Logistics & ImportRegular weekly shipments from our Far East partners and smooth customs processes.
Quote
Get a quote for your PCB and PCB assembly project
Fill in the form: your request reaches our team directly and we reply quickly.
